We start our conversions with E-Z GO TXT carts. These are refurbished vehicles that typically have less then 2 years run time on them. Service and parts are usually available nationally and all the drive components remain standard equipment. This works well as the foundation for our build. They are reliable, durable and a proven product. The basic specifications are noted below.

With the quality E-Z GO product, we customize the vehicle with no cutting or damage to the existing systems in place. Our utility vehicles are retrofitted with engineered systems that do not require cutting or welding to the base vehicle. Our design utilizes the existing mounting points and we relocate components that can always be returned to factory specifications later. We build each custom vehicle with years of use in mind.


Frame: Welded steel with powder coating

Front Body & Finish: Injection-molded TPO

Rear Body & Finish: Injection-molded TPO

Standard Color: Ivory or Forest Green



Overall Length: 93.0 in (236 cm)

Overall Width: 47.0 in (119 cm)

Overall Height (no canopy): 46.5 in (118 cm) (top of steering wheel)

Overall Height (with canopy): 67.5 in (171 cm) (top of sun canopy)

Wheel Base: 66.0 in (168 cm)

Front Wheel Track: 34.0 in (86 cm)

Rear Wheel Track: 38.5 in (97 cm)

Ground Clearance (at differential): 4.5 in (11 cm)



Power Source: 48-volt DC

Motor Type: Shunt Wound

Horsepower (kW): 3.0 hp (2.2 kW) Continuous

Electric System: 48-volt

Batteries (qty/type): Six, 8-volt deep cycle

Key or Pedal Start: Pedal

Battery Charger: 48 VDC PowerWise™ QE, 120 VAC, UL & CSA

Speed Controller: 250-amp solid-state controller

Drive Train: Motor shaft direct drive

Transaxle: Differential with helical gears

Gear Selection: Dash-mounted forward-neutral-reverse

Rear Axle Ratio: 12.44:1


Standard: 20,000 amp/hr

Platinum: 21,500 amp/hr - optional

Diamond: 25,000 amp/hr - optional

TruCourse Programmable Modes: Coastal, Mild hill, Steep hill



Seating Capacity: 2-person

Dry Weight (without batteries): 557 lb (253 kg)

Curb Weight: 935 lb (424 kg)

Vehicle Load Capacity: 800 lb (363 kg)

Outside Clearance Circle: 19.0 ft (5.8 m)

Speed (level ground): 10.2-14.8 mph (16.4-23.8 kph)

Towing Capacity: 3 E-Z-GO golf cars with approved permanent tow bar



Steering: Self-compensating rack and pinion

Front Suspension: Leaf springs with hydraulic shock absorbers

Rear Suspension: Leaf springs

Service Brake: Rear wheel mechanical self-adjusting drum

Parking Brake: Self-compensating single-point engagement

Front Tires: 18 x 8.50-8 (4-ply rated)

Rear Tires: 18 x 8.50-8 (4-ply rated)
